Specification
Projection System: 3LCD (3×0.64″ with MLA)
Native Resolution: 1920×1200
Brightness: 6000 (ANSI Lumens)
Brightness (Center Lumens): 6500
Contrast Ratio: 3000000:1
Display Color: 1.07 Billion Colors
Light Source Type: Laser Phosphor
Light Source Life (hours) with Normal Mode: 20000
Light Source Life (hours) with SuperEco Mode: 30000 (Eco)
Lens: F=1.58-2.02, f=15.3-24.6mm
Projection Offset: 0%+/-5%
Throw Ratio: 1.08-1.76
Optical Zoom: 1.6X
Digital Zoom: 1.0x-4.0x
Image Size: 30″-300″
Throw Distance: 0.70-11.37m
(100″@2.33m)
Keystone: H:+/-30° , V:+/-30°
Lens Shift V. Range: +45%, 0%
Lens Shift H. Range: +21%, -21%
Audible Noise (Normal): 35dB
Audible Noise (Eco) : 25dB
Input Lag: 60ms
Resolution Support: VGA(640 x 480) to 4K(3840 x 2160)
HDTV Compatibility: 480i, 480p, 576i, 576p, 720p, 1080i, 1080p, 2160p
Horizontal Frequency: 15K-100KHz
Vertical Scan Rate: 23-85Hz
Input
Computer in (share with component): 1
HDMI: 2
(HDMI 1.4/ HDCP 1.4)
Audio-in (3.5mm): 1
USB Type A: 1 (5V/2A)
HDBaseT: 1
Output
Monitor out: 1
Audio-out (3.5mm): 1
Speaker: 16W
USB Type A (Power): 1
(USB2.0 – 5V/2A,
share with USB A Input)
Control
RS232 (DB 9-pin male): 1
RJ45 (LAN control): 1
USB Type B (Services): 1
Others
Power Supply Voltage: 100-240V+/- 10%, 50/60Hz
(AC in)
Power Consumption: Normal: 330W
Standby: Operating Temperature: 0~40℃
Carton: Brown
Net Weight: 7.9kg
Gross Weight: 10.93kg
Dimensions (WxDxH) with Adjustment Foot: 405x358x137mm
Packing Dimensions: 510x498x260mm
OSD Language: English, German, French, Italian, Spanish, Polish, Swedish, Dutch ,Portugese, Japanese, Simplified Chinese, Traditional Chinese, Korean, Russian, Turkish, Finnish, Norwegian, Danish, Indonesian, Hungarian, Czech, Kazak, Vietnamese,Thai, Farsi, total 25 languages
User Guide Language: English, S-Chinese, T-Chinese, Indonesian, Finish, French, German, Italian, Japanese, Korean, Polish, Portuguese, Russian, Spanish, Swedish, Turkish, Arabic, Czech, Thai, Vietnamese, total 20 languages
Standard Accessory
Power Cord: 1
Remote Control: 1
QSG: Yes
Air Filter: Yes
Warranty Card: Yes (CN Only)
Optional Accessory
Air Filter: Yes
Wall/Ceiling Mount: PJ-WMK-007
